Tủ sấy đối lưu không khí cưỡng bức

Price: Quick contact
Model: Venticell 55 - ECO
Producer: MMM - GERMANY
Origin : Đức/EU
Status :Còn hàng
Technical data
Inner space volume l 22 55 55-2 111 111-2 222 222-2 404 404-2 707 707-2
width mm 240 400 400 540 540 540 540 540 540 940 940
depth mm 320 370 370 370 370 520 520 520 520 520 540
height mm 300 350 350 530 530 760 760 1410 1410 1410 1410
External dimensions
((including door, handle,
legs N or casters K)
width max. mm 406 620 620 760 760 760 760 760 760 1160 1160
depth max. mm 560 640 660 640 660 790 806 790 806 790 806
height max. mm 610N 680N 680N 860N 860N 1095N 1110N 1910K 1910K 1910K 1910K
ventilation neck diameter -
internal / external
mm 52/49 52/49 52/49 52/49 52/49 52/49 52/49 52/49 52/49 52/49 52/49
Package – basic package width approx mm 500 700 700 830 830 860 860 830 830 1230 1230
depth approx mm 720 730 730 730 730 860 860 860 860 860 860
height (including palette) approx mm 810 875 875 1060 1060 1260 1260 2085 2085 2085 2085
Package - case width approx mm 720 780 780 810 810 920 920 910 910 1335 1335
depth approx mm 780 800 800 910 910 960 960 970 970 1060 1060
height (including palette) approx mm 835 900 900 1085 1085 1310 1310 2123 2123 2163 2163
Package – wooden crate width approx mm - 780 780 900 900 900 900 910 910 1310 1310
depth approx mm - 800 800 800 800 940 940 940 940 940 940
height (including palette) approx mm - 870 870 1090 1090 1270 1270 2120 2120 2120 2120
Trays / shelves maximal number pc 4 4 4 7 7 10 10 19 19 19 19
standard equipment pc 2 2 2 2 2 2 2 2 2 2 2
minimal distance between
trays/shelves
mm 60 70 70 70 70 70 70 70 70 70 70
usable area mm 185×265 380×335 380×335 520×335 520×335 520×485 520×485 520×485 520×485 920×485 920x485
Maximal allowed loading
of trays *)
per 1 tray kg 10 20 20 20 20 30 30 30 30 50 50
per 1 shelf kg 10 20 20 20 20 30 30 30 30 20 20
inside the device - in total kg 25 50 50 50 50 70 70 100 100 130 130
Number of external metal door pc 1 1 2 1 2 1 2 1 2 2 4
Weight net approx kg 31 55 60 75 80 100 105 150 160 215 230
gross (cartoon) approx kg 36 66 71 87 92 116 121 175 185 240 255
Electric data
– mains 50/60 Hz
max. input kW 0,96 1,3 1,9 1,9 2,5 1,9 3,7 3,7 5,5 4,9 7,3
stand by input W 5 5 5 5 5 5 5 5 5 5 5
current for voltage **) A 4,2 5,6 8,3 8,3 10,6 8,3 5,6 5,6 8,3 7,8 15,6
V 230 230 230 230 230 230 400/3NPE 400/3NPE 400/3NPE 400/3NPE 400/3NPE
current for voltage **) A 8,4 11,3 16,6 16,6 21,2 16,6 19 19 28 28 42
V 115 115 115 115 115 115 115/3PE 115/3PE 115/3PE 115/3PE 115/3PE
Degree of coverage IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Temperature data
Operation temperature from 10°C above ambient
temperature
to°C 250/300 250/300 250/300 250/300 250/300 250/300 250/300 250/300 250/300 250/300 250/300
Variations from operation
temperature with closed
flap and door (DIN 12 880
part 2)
space %
temperature
1,1 1 2 1 1 1 1,2 1,5 1,8 2,5 2,5
time ±°C 0,3 0,3 1,2 0,4 0,4 0,4 0,4 0,4 0,4 0,4 0,74
Time to reach temperature of 250°C with closed flap
and voltage 230 V
min 28 49 - 53 - 70 33 58 43 64 50
Number of air exchanges at 250°C per hour 45 45 45 49 49 24 24 18 18 12 12
Heat losses at 250°C W 420 590 590 760 760 990 990 1940 1940 2550 2550
